Description
The Falcon TP70T D 625 is a heavy-duty mortise lock designed for commercial environments including offices, hospitals, and educational facilities. This MA Series lock combines security with durability, featuring a two-piece stainless steel latch bolt and a one-inch throw deadbolt with saw-resistant rollers. It solves the need for reliable, long-lasting access control in high-traffic applications.
The lock accommodates door thicknesses from 1-3/8" to 2-1/2" and features an interchangeable core (SFIC compatible) for easy re-keying without removing the lock body. Right-hand handing is standard; left-hand and field reversible options are available. As an authorized Falcon dealer, E.D. Locks provides expert guidance on specification, installation, and keying. Contact sales@edlocks.com or call 1-877-207-6067 for personalized support.
Specifications
- Brand: Falcon (Allegion)
- Model: TP70T D 625
- Door Thickness: 1-3/8" to 2-1/2"
- Backset: 2-3/4"
- Case: Cold formed steel, zinc dichromate plated, 0.090" thick
- Latch Bolt: 3/4" projection, two-piece stainless steel
- Deadbolt: 1" throw with saw-resistant rollers
- Cylinders: Solid brass, 5, 6, or 7-pin standard; 6 or 7-pin interchangeable core
- Keyways: G (standard cylinder), A (I/C cylinder)
- Faceplate: 1-1/4" x 8" brass or stainless steel
- Handing: Right hand standard, left hand optional, field reversible
- Electrified: Available 12 or 24 VDC
- ANSI/BHMA: 156.13, Series 1000
- UL: 3 hour A label
