Description
The Falcon TP70T Q 630 is a heavy-duty mortise lock built for commercial environments like offices, hospitals, and educational facilities. Its MA Series delivers dependable security and smooth operation under constant use, featuring an interchangeable SFIC core for quick re-keying and compatibility with other manufacturers' SFIC products.
This lock accommodates door thicknesses from 1-3/8" to 2-1/2" with a 2-3/4" backset and includes a 1" stainless steel dead bolt with saw-resistant rollers. Right-hand handing is standard with left-hand and field-reversible options available. Contact E.D. Locks at sales@edlocks.com or 1-877-207-6067 for expert keying assistance and authorized dealer support.
Specifications
- Door Thickness: 1-3/8" to 2-1/2"
- Backset: 2-3/4"
- Case: Cold formed steel, zinc dichromate plated, 0.090" thick
- Hubs: Hardened steel
- Cylinders: Solid brass, 5, 6, or 7-pin standard; 6 or 7-pin on I/C core
- Keyways: "G" standard cylinder, "A" standard I/C cylinder
- Latch Bolt: Two-piece stainless steel, 3/4" projection
- Dead Bolt: 1" throw, stainless steel with saw-resistant rollers
- Faceplates: 1-1/4" x 8", brass or stainless steel, adjustable for door bevel
- Electrified: Available 12 or 24 VDC
- ANSI/BHMA: Series 1000
- UL: 3-hour A label
