Description
The Falcon TP70T Q 613 is a heavy-duty mortise lock built for high-traffic commercial environments including offices, hospitals, and educational facilities. Its MA Series design combines robust security with dependable performance under constant use, featuring a two-piece stainless steel latch bolt and a 1-inch throw dead bolt with saw-resistant rollers for superior protection.
This lock accommodates door thicknesses from 1-3/8" to 2-1/2" and ships with a 2-3/4" backset. The interchangeable core cylinder enables quick re-keying and works with SFIC products from other manufacturers. As an authorized Falcon dealer, E.D. Locks provides expert guidance on keying options, handing, and electrified configurations. Contact sales@edlocks.com or call 1-877-207-6067 for personalized assistance.
Specifications
- Brand: Falcon
- Model: TP70T Q 613
- Door Thickness: 1-3/8" to 2-1/2"
- Backset: 2-3/4" only
- Case: Cold formed steel, zinc dichromate plated, 0.090" thick
- Latch Bolt: Two-piece stainless steel, 3/4" projection
- Dead Bolt: 1" throw stainless steel with saw-resistant rollers
- Cylinders: Solid brass, 5, 6, or 7-pin standard; 6 or 7-pin interchangeable core
- Handing: Right hand standard; left hand optional, reversible in field
- Faceplates: 1-1/4" x 8" brass or stainless steel, adjustable for door bevel
- Electrified: Available in 12 or 24 VDC
- Certification: ANSI/BHMA 156.13 Series 1000, UL 3 hour A label
