Description
The Falcon TP75E S 626 is a heavy-duty mortise lock built for commercial environments including offices, hospitals, and educational facilities. It features an interchangeable core for quick re-keying, a mechanical anti-friction latch bolt, and a saw-resistant dead bolt with 1-inch throw. Designed for constant use without fail.
This lock accommodates door thicknesses from 1-3/8" to 2-1/2" with a standard 2-3/4" backset and is reversible in the field for left or right-hand installation. It meets ANSI/BHMA Series 1000 and carries a 3-hour UL label. Contact our authorized dealer team at sales@edlocks.com or 1-877-207-6067 for expert guidance on keying, compatibility, and installation support.
Specifications
- Brand: Falcon
- Model: TP75E S 626
- Door Thickness: 1-3/8" to 2-1/2"
- Backset: 2-3/4" only
- Case: Cold formed steel, zinc dichromate plated, 0.090" thick
- Hubs: Hardened steel
- Handing: Right hand standard; left hand optional; reversible in field
- Cylinders: Solid brass; 5, 6, or 7-pin available
- Latch Bolt: Two-piece stainless steel, 3/4" projection
- Dead Bolt: 1" throw, stainless steel with saw-resistant rollers
- Faceplates: 1-1/4" x 8", brass or stainless steel, adjustable for bevel
- Electrified Functions: 12 or 24 VDC available
- Standards: ANSI/BHMA 156.13 Series 1000; UL 3-hour A label
- Includes: Two nickel silver keys
