Description
The Sargent 2870-7G04 LL is a key-in-lever lock built for standard-duty commercial use in public buildings, medical offices, hotels, and government facilities. This ANSI/BHMA A156.2 certified lock delivers reliable security and durability for interior and exterior doors in high-traffic environments where professional-grade hardware is required.
Designed for 1-3/4" thick doors with a 2-3/4" backset (other sizes available), this lock features a brass 1/2" throw latch, steel cylindrical housing, and your choice of wrought brass or stainless steel front and strike. Two nickel silver keys and a 6-pin LA keyway cylinder come standard; master keying and grand master keying are available. Contact E.D. Locks at sales@edlocks.com or 1-877-207-6067 for expert guidance on keying options and installation.
Specifications
- Standard Door Thickness: 1-3/4" (44mm); specify 1- for 1-3/8" (35mm)
- Standard Backset: 2-3/4" (70mm); specify 20- for 2-3/8" (60mm)
- Cylindrical Housing: Steel, zinc dichromate finish
- Front Plate: 2-1/4" x 1-1/8" standard; 2-1/4" x 1" with 20- option
- Latch: Brass, 1/2" (13mm) throw
- Strike: 2-3/4" curved lip standard; 4-7/8" curved lip (28-) and 2-1/4" full lip (14-) optional
- Cylinder: Brass, 6-pin, LA keyway standard
- Keys: Two nickel silver
- Hand Options: Non-handed B, L, P designs; handed G and Y Coastal Series designs
- Finish Options: 03, 04, 09, 10, 10B, 10BE, 10BL, 14, 15, 20D, 26, 26D
- Master Keying: Available; can be grand master keyed
- Door Prep: ANSI A115.2; specify 20- for 160 prep
