Description
The Adams Rite 3701M-42 is a rim exit device designed for 42-inch openings on standard 1-3/4" thick doors. Built for fire-rated applications, this aluminum pushbar device is ideal for commercial buildings, healthcare facilities, and any property requiring reliable emergency egress control and request-to-exit functionality.
The 3701M-42 features a field-reversible lever entry trim and standard dogging with hex key operation. It is compatible with standard mortise cylinders (MS cam) and includes stainless steel strikes. As an authorized Adams Rite dealer, E.D. Locks provides expert sizing guidance and keying support. Contact sales@edlocks.com or call 1-877-207-6067 for handing, finish selection, and cylinder configuration assistance.
Specifications
- Brand: Adams Rite
- Model: 3701M-42
- Pushbar Length: 42 inches
- Door Thickness: 1-3/4" standard (modifiable for thicker doors)
- Material: Extruded aluminum, clad or anodized
- Projection: 2-5/8" when fully projected, 1-5/8" when dogged
- Minimum Stile Width: 5 inches
- Dogging: Standard dogging with hex key
- Strike Material: Stainless steel
- Cylinder Compatibility: Standard mortise cylinder with MS cam
- Fasteners: Self-tapping screws (optional Sex Bolt Kits available)
- Warranty: Five year limited
