Description
The Adams Rite 8801C-42 is a rim exit device designed for narrow-stile aluminum doors in commercial and institutional settings. With cylinder dogging and a 42-inch pushbar, it provides reliable emergency egress while allowing authorized personnel to lock down the door when needed. The extruded aluminum construction is available in multiple finishes to match your building's aesthetic.
This non-handed device fits standard 1 3/4" to 2 1/4" door thickness and adjusts from 30" to 44" bar height, accommodating doors up to 8 feet tall. Installation uses standard self-tapping screws on aluminum stiles. As an authorized Adams Rite dealer, E.D. Locks provides expert guidance on cylinder selection, keying, and compatibility. Contact our team at sales@edlocks.com or 1-877-207-6067 for technical support and to confirm your door specifications before ordering.
Specifications
- Brand: Adams Rite
- Model: 8801C-42
- Product Type: Rim Exit Device
- Application: Narrow Stile Aluminum Doors
- Pushbar Length: 42 inches
- Dogging: Cylinder Dogging
- Material: Extruded Aluminum
- Bar Height Adjustment: 30" to 44"
- Door Thickness: 1 3/4" to 2 1/4"
- Maximum Door Height: 8 feet (with bar height at 40-44 inches)
- Stile Width Minimum: 3 3/4"
- Projection: 2 15/16" when fully projected, 1 15/16" when dogged
- Handing: Non-handed, lever entry trim field reversible
- Fasteners: Standard self-tapping screws
- Cylinder Compatibility: Accepts standard rim cylinders
- Warranty: Five year limited
