Description
The Sargent 80 Series MD8673F is a left-hand reverse rim exit device engineered for commercial metal doors requiring ANSI/BHMA Grade 1 security and durability. Ideal for offices, schools, and facilities prioritizing life-cycle reliability, this device features modular construction, minimal moving parts, and maintenance-free operation that exceeds industry standards.
Installation suits metal doors 1-3/4" minimum thickness with 4-1/2" minimum stile width; rails are factory-cut based on door width (E, F, J, or G rail options for 24-48" openings). Includes 650 top and 606 bottom strikes with standard hex-key dogging. Contact our authorized dealer team at sales@edlocks.com or 1-877-207-6067 for application guidance, electric options (alarm, beacon, photoluminescent, delay egress, latch retraction), and expert configuration support.
Specifications
- Model: MD8673F LHR 20D
- Brand: Sargent
- Series: 80 Series
- Configuration: Rim, left-hand reverse
- Door Types: Metal doors, 1-3/4" (44mm) minimum thickness
- Stile Width: 4-1/2" (114mm) minimum
- Rail Options: E (24-32"), F (33-36"), J (37-42"), G (43-48")
- Strikes: 650 Top, 606 Bottom (panic and fire-rated)
- Dogging: Hex key standard; cylinder dogging available (#41 cylinder)
- Device Centerline: 41" standard, 38" for elementary schools
- Center Case: 8-3/8" x 2-5/8"
- Pushbar Projection: 3" neutral, 2-1/8" depressed
- Max Door Height: 96"
- Top Bolt: Stainless steel
