Description
The Sargent 80 Series exit device is a heavy-duty panic bar for metal doors requiring ANSI/BHMA Grade 1 security and reliability. Ideal for commercial facilities, schools, and hospitals, this rim-mounted device solves the critical need for compliant, durable emergency egress hardware that performs through the life of the building.
This left-hand reverse (LHR) model fits metal doors 1 3/4" to 2 1/4" thick with modular construction and minimal maintenance. Choose from multiple rail sizes (E, F, J, G) matched to your door width, and optional electric features including delayed egress, alarms, and latch monitoring. Contact E.D. Locks at sales@edlocks.com or 1-877-207-6067 for expert specification guidance and authorized dealer support.
Specifications
- Brand: Sargent
- Model: 55-MD8674F LHR 20D
- Configuration: Rim-mounted, left-hand reverse
- Door Thickness: 1 3/4" to 2 1/4" (44-57mm)
- Minimum Stile Width: 4 1/2" (114mm)
- Device Centerline Height: 41" (1041mm) standard; 38" (965mm) for ADA/elementary
- Center Case: 8 3/8" x 2 5/8" (213mm x 67mm)
- Pushbar Projection: 3" neutral, 2 1/8" depressed (76mm, 54mm)
- Strike: 650 top, 606 bottom (panic and fire-rated)
- Dogging: Hex key standard; cylinder dogging available
- Rail Options: E (24-32"), F (33-36"), J (37-42"), G (43-48")
- Electric Options: Alarm, beacon, photoluminescent, illuminated touchpad, latch monitoring, RTE signal, remote latch retraction, delayed egress, electric dogging, Electroguard
- Max Door Height: 96"
- Fasteners: Machine screws supplied
