Description
The Falcon TP70T D 606 is a heavy-duty mortise lock built for high-traffic commercial environments like offices, hospitals, and educational facilities. It features an interchangeable core for quick re-keying, a stainless steel deadbolt with saw-resistant rollers, and a two-piece anti-friction latch bolt. This tough, dependable lock handles constant use without fail.
Accommodates door thickness 1-3/8" to 2-1/2" with a 2-3/4" backset. Compatible with SFIC products and available with 5, 6, or 7-pin cylinders. As an authorized Allegion dealer, E.D. Locks provides expert support for your commercial security needs. Contact our team at sales@edlocks.com or 1-877-207-6067 for keying options and installation assistance.
Specifications
- Door Thickness: 1-3/8" to 2-1/2"
- Backset: 2-3/4"
- Case: Cold formed steel, zinc dichromate plated, 0.090" thick
- Latch Bolt: Two-piece stainless steel, 3/4" projection
- Dead Bolt: 1" throw, stainless steel with hardened steel rollers
- Faceplates: 1-1/4" x 8" brass or stainless steel
- Cylinders: 5, 6, or 7-pin solid brass available
- Handing: Right hand standard; left hand optional, reversible
- ANSI/BHMA: 156.13 Series 1000
- UL: 3 hour A label
- Electrified: Available in 12 or 24 VDC
