Description
The Falcon TP70T S 606 is a mortise lock built for high-traffic commercial environments including offices, hospitals, and educational facilities. Its MA Series design combines security with durability to withstand constant use without fail, making it ideal for projects demanding dependable performance at an affordable price point.
This lock features an interchangeable core (SFIC-compatible) for quick re-keying and fits standard door thicknesses from 1-3/8" to 2-1/2". For expert guidance on handing, keying options, electrified configurations, or installation support, contact our authorized dealer team at sales@edlocks.com or 1-877-207-6067.
Specifications
- Door Thickness: 1-3/8" to 2-1/2"
- Backset: 2-3/4"
- Case: Cold formed steel, zinc dichromate plated, 0.090" thick
- Hubs: Hardened steel
- Handing: Right hand standard, left hand optional, reversible in field
- Cylinders: Solid brass, 5, 6, or 7-pin standard; 6 or 7-pin I/C available
- Keyways: G keyway standard cylinder, A keyway I/C cylinder
- Latch Bolt: Two-piece stainless steel, 3/4" projection
- Dead Bolt: 1" throw, stainless steel with saw-resistant rollers
- Faceplates: 1-1/4" x 8" brass or stainless steel, adjustable for door bevel
- Strike: Brass or stainless steel, meets ANSI A115.1
- Electrified: Available 12 or 24 VDC
- ANSI/BHMA: Series 1000 (ANSI/BHMA 156.13)
- UL Rating: 3 hour A label
