Description
The Falcon TP95E D 630 is a heavy-duty mortise lock built for commercial offices, hospitals, and educational facilities that demand dependable security and frequent use tolerance. Its rugged construction, anti-friction latch, and saw-resistant dead bolt rollers deliver years of reliable performance in high-traffic environments without compromising ease of operation.
This lock accommodates standard door thickness of 1-3/8" to 2-1/2" and features an interchangeable core (SFIC compatible) for quick re-keying without removing the lock body. As an authorized Falcon dealer, E.D. Locks provides expert specification guidance and keying support. Contact our sales team at sales@edlocks.com or 1-877-207-6067 for compatibility questions or custom configuration options.
Specifications
- Brand: Falcon
- Model: TP95E D 630
- Door Thickness: 1-3/8" to 2-1/2"
- Backset: 2-3/4"
- Latch Bolt: 3/4" projection, two-piece stainless steel, mechanical anti-friction
- Dead Bolt: 1" throw, stainless steel with saw-resistant rollers
- Case: Cold formed steel, zinc dichromate plated, 0.090" thick
- Cylinders: Solid brass, 5, 6 or 7-pin standard; 6 or 7-pin SFIC
- Standard Keyway: G (standard cylinder), A (SFIC)
- Handing: Right hand standard, left hand optional, reversible
- Keys Furnished: Two nickel silver keys
- Faceplate: 1-1/4" x 8" brass or stainless steel, adjustable for door bevel
- Strike: Brass or stainless steel, ANSI A115.1 compliant
- Electrified: Optional 12 or 24 VDC
- Certifications: ANSI/BHMA 156.13 Series 1000, UL 3 hour A label
