Description
The Falcon TP95E S 605 is a heavy-duty mortise lock built for demanding commercial environments including offices, hospitals, and educational facilities. This MA Series lock delivers dependable security and withstands constant use without failure, featuring an interchangeable core for quick re-keying and compatibility with SFIC products from other manufacturers.
The TP95E S 605 accommodates standard door thicknesses of 1-3/8" to 2-1/2" with a 2-3/4" backset. Right-hand handing is standard; left-hand and field-reversible options are available. As an authorized Falcon dealer, E.D. Locks provides expert guidance on installation, keying, and customization. Contact our sales team at sales@edlocks.com or 1-877-207-6067 for technical assistance and competitive pricing on this ANSI/BHMA Series 1000 certified lock.
Specifications
- Case: Cold formed steel, zinc dichromate plated, 0.090" thick; optional lead wrapping available
- Door thickness: 1-3/8" to 2-1/2"
- Backset: 2-3/4" only
- Hubs: Hardened steel
- Cylinders: Solid brass; 5, 6, or 7-pin standard; 6 or 7-pin on interchangeable core
- Latch bolt: Two-piece stainless steel, mechanical anti-friction, 3/4" projection
- Dead bolt: 1" throw, stainless steel with two 13/16" diameter hardened steel, free-turning, saw-resistant rollers
- Faceplates: 1-1/4" x 8" brass or stainless steel, adjustable for door bevel
- Strike: Brass or stainless steel, non-handed, meets ANSI A115.1
- Electrified functions: 12 or 24 VDC available
- ANSI/BHMA: Meets ANSI/BHMA 156.13, Series 1000
- UL: 3 hour A label
- Furnished with two nickel silver keys; keyways: G (standard) or optional
