Description
The Sargent 80 Series exit device is a heavy-duty panic hardware solution designed for commercial facilities requiring reliable emergency egress. Built to exceed ANSI/BHMA Grade 1 standards, this rim-mounted device combines durable construction with minimal maintenance, making it ideal for wood or metal doors in high-traffic environments.
This left-hand reverse (LHR) model fits standard 1-3/4" doors with stile widths from 24" to 48" depending on rail configuration. Sargent offers optional delayed egress, alarmed exit, and electric latch retraction functions for specialized applications. Contact our experts at sales@edlocks.com or 1-877-207-6067 for sizing guidance and to ensure proper configuration for your door frame.
Specifications
- Brand: Sargent
- Series: 80 Series
- Model: 194356-8343E LHR 10B
- Type: Rim Exit Device
- Handedness: Left-Hand Reverse (LHR)
- Compatible Door Thickness: 1-3/4" (44mm)
- Minimum Stile Width: 4-1/2" (114mm)
- Door Width Range: 24" to 48" depending on rail
- Standards: Exceeds ANSI/BHMA Grade 1
