Description
The Falcon TP70T D 613 is a high-performance mortise lock designed for commercial environments including offices, hospitals, and educational facilities. Built to withstand constant use, this MA Series lock delivers dependable security with an interchangeable core that enables quick re-keying without removing the lock from the door.
Compatible with standard SFIC products, this lock accommodates door thicknesses of 1 3/8 inches to 2 1/2 inches with a 2 3/4 inch backset. As an authorized Falcon dealer, E.D. Locks provides expert guidance on cylinder pin configurations, keyway options, and electrified functions. Contact our team at sales@edlocks.com or 1-877-207-6067 for detailed compatibility assistance and fast shipping.
Specifications
- Brand: Falcon
- Model: TP70T D 613
- Door Thickness: 1 3/8 inches to 2 1/2 inches
- Backset: 2 3/4 inches
- Case Material: Cold formed steel, zinc dichromate plated, 0.090 inches thick
- Hubs: Hardened steel
- Handing: Right hand standard; left hand optional, reversible in field
- Cylinders: Solid brass, 5, 6, or 7-pin standard; 6 or 7-pin interchangeable core
- Keyways: G standard on standard cylinder, A standard on interchangeable core
- Latch Bolt: Two-piece stainless steel, 3/4 inch projection
- Dead Bolt: 1 inch throw stainless steel with two 13/16 inch hardened steel roller bearings
- Faceplates: 1 1/4 inches x 8 inches, brass or stainless steel, adjustable for bevel
- Strike: Brass or stainless steel, ANSI A115.1 compliant, non-handed
- Electrified Functions: Available 12 or 24 VDC
- Standards: ANSI/BHMA 156.13 Series 1000, UL 3 hour A label
